Setup
Refer to the instructions below to setup the Mycube Fire Gen 3:
External Battery Pack Setup:
1. Insert the 4 AAA batteries into the battery pack (included with your safe)
2. Connect the USB-C cord on the battery pack to the emergency power terminal port on the side of the keypad
Passcode Setup:
1. Press START, then enter the 6-digit factory passcode 123456, then START again
2. Turn the knob to the right (clockwise) to open the safe
3. Insert 4 AA batteries into the battery compartment on the back of the safe door
4. Once the batteries are installed, press the ‘Memory' button found on the back of the safe door
5. Once the ‘Memory' button is pressed, enter a code (4 - 20 digits) followed by START (remember and record this code in a safe place)
6. Enter the code a second time to verify
7. Press START again
Fingerprint Setup:
1. Open the door and press the memory button* 3 for seconds (*located on the lower left section of the interior side of the door)
2. “Set” will be displayed
3. Press the memory button once again
4. “FinPr” will be displayed
5. Press “0”
6. “EnroLL” will be displayed
7. Place your finger on the sensor when [ ] is displayed
8. Place your fingerprint on the sensor 3 consecutive times
9. Your ID number will be displayed
Installation
Refer to the link below to access the Mycube Fire Installation Instructions:
Mycube Fire Installation Instructions
Opening & Closing Your Safe
To Open the Safe - With Passcode:
Press Start
Input 6-digit. passcode
Turn the knob to the right (clocwise)
To Open the Safe - With Fingerprint:
Press Start
Place your registered finger on the fingerprint scanner
Turn the knob to the right (clockwise)
To Close the Safe:
Close the door
Turn the knob to the left (counterclockwise)
You can also refer to the link below for a visual representation of this process:
Mycube Fire Gen 3 - Open & Closing Instructions
Reset Code
Refer to the steps below to reset your passcode:
1. Open the door and press the memory button* (*located on the lower left section of the interior side of the door)
2. “CodE-“ will be displayed, then “_____” will be displayed
3. Enter the new passcode + Start ( 4- 20 digits)
4. Enter the new passcode again
5. When “_____” is displayed, press Start
6. After the new passcode is set, double-check it with the door open
Sound Effects
Refer to the steps below to control the volume on your safe:
1. Open the door and press the memory button* for 3 seconds (*located on the lower left section of the interior side of the door)
2. Press the Start button twice
3. “VoL” will be displayed
4. Select volume level 0 - 7
5. Press Start after the desired volume level is selected
Keypad Lock Mode
Refer to the steps below to lock and unlock your keypad:
Lock:
1. Press and hold the Start button for more than 10 seconds to lock the keypad
2. “ACE” will appear
Note: If you cannot enter the keypad lock mode, wait until the screen is turned off, then follow Step #1.
Unlock:
1. Press and hold the Start button for 3 seconds to deactivate the keypad lock
2. “dEACE” will appear
Fingerprint Deletion
Refer to the steps below to delete registered fingerprint(s):
To delete one of the registered fingerprints:
1. Open the door and press the memory button* for 3 seconds (*located on the lower left section of the interior side of the door)
2. “Set” will be displayed
3. Press the memory button again
4. “FingPr” will be displayed
5. Press “0
6. “Id_” will be displayed, then “dELEtE” will be displayed
7. Input ID number (0-9*) to delete (*this is the number linked to the fingerprint you want to delete)
8. Press Start
Note: If “Id-no” is displayed, no fingerprint exists for that ID. If “no-FP” is displayed, there are no fingerprints to delete.
To delete all fingerprints:
1. Open the door and press the memory button* for 3 seconds (*located on the lower left section of the interior side of the door)
2. “Set” will be displayed
3. Press the memory button again
4. “FingPr” will be displayed
5. Press “0
6. Press the memory button
Alarm Device
The Mycube Fire Gen 3 safe has an alarm that will sound when your safe is impacted or tilted. This alarm is powered by 3 AAA batteries that must be replaced every 6 months. Refer to the instructions below to activate/deactivate your alarm:
1. Insert 3 AAA batteries into the alarm device
2. Press the On/Off Switch once to activate the alarm
3. Press the On/Off switch once to deactivate the alarm
Note: Be careful of hearing damage to pregnant people or the elderly.
